What is FMB in land?

The government at the respective Tashildar's office keeps all the map data in the form of a sketch which is restored in a book. This book is known as Field Measurement Book or FMB in land. The survey number is individually preserved at a scale of 1:1000 or 1:2000. Survey numbers are categorized into various sub-divisions. The sub-division number helps to identify the property owner. FMB determines the accurate dimensions of the land. We need the FMB sketch to check the land measurement and boundaries of the property while purchasing a property. Therefore, it is extremely crucial to understand what is FMB sketch meaning. The FMB sketch full form is Field Measurement Book.

Elements of FMB

G-Line The G-line is crucial for the outline of the entire sketch. This line is an imaginary line that assists in transforming the sketch into different shapes of triangles to fix the boundary lines and different points in the sketch. A G-line can affect the calculation if it contains an error. F-Line In the sketch, the actual field boundaries are denoted by the F-line. The points of the F-line remain fixed in reference to G-line according to offset distance. Subdivision Line The sub-division line plays an important role in fmb sketch. The ladder generally defines the subdivisions lines. Sub-division lines refer to the small area with the survey numbers. Ladder The field line points which are signified by referring to the offset distance from the G-line is called the ladder. When you transform the ladder details to electronic data you can get the FMB sketch Extension Lines The subject field intersecting at the neighbouring fields on the FMB is the extension line. Neighbouring Field Survey Number The survey sketch of other fields surrounding each other with separate field numbers is called the neighbouring field survey numbers. I hope you know now what is FMB sketch meaning.

As Harsh mentioned the FMB full form in survey is the Field Measurement Book. FMB is an essential part of land surveying as it serves as a logbook for all measurements and information gathered during the surveying process. Let’s learn more about FMB below.

What is FMB meaning in land?

 FMB gives thorough details including calculation of angles, sketches, or drawings of the ground. This book ensures accuracy, transparency, and legal validity. I have read a number of answers provided above, and everyone was very well stated regarding the FMB. Let’s check out the process I have followed to get FMB copy:

• Go to

  https://onlineap.meeseva.gov.in/CitizenPortal/UserInterface/Citizen/Home.aspx

  .

• Sign in with your User ID, Password, and Captcha.

• Go to Services and click on Revenue Department.

• Now tap on the FMB Copy button.

• Mention the required details like district, village, survey number, and so on.

• Tap on Get Details.

• Now input your personal details and upload all the needed documents.

• Confirm your payment.

• Finally, you can now download or print FMB Copy Certificate.

FMB book is useful for both land administration and surveyors, assuring precision, transparency, and legal validity. Additionally, it offers precise data on current land features like roads, buildings, and utilities.

Hire NoBroker’s Legal Experts to get help with property! Read more -

How to apply for FMB sketch online in Tamil Nadu?

How to view and download FMB sketch online?



I checked out the answers written by Mr Harsh and Mr Aniket about FMB meaning. Although they have written a very precise definition of FMB land, I will try to share the definition of FMB land in my own words. The FMB full form in land is Field Measurement Book. Field Measurement Book consists of map data that is stored in volumes by the government at the Tahsildar office. The survey number of FMB sketches is maintained at a scale of 1:1000  or 1:2000. Each survey number has various sub-division numbers and each sub-division number belongs to the property owner. FMB sketch contains the correct dimensions of the land.

  To avoid purchasing land with discrepancies, hire NoBroker to run due diligence of property!

I saw Mr Aniket mentioning how to check FMB sketch in Kerala, so I will mention the process of Tamil Nadu.

How to check FMB sketch in Tamil Nadu?

1. Go to the official website of FMB land sketch at:

https://eservices.tn.gov.in/eservicesnew/land/chitta.html?lan=en



1. Click on the “view Patta Chitta FMB Map TSLR Extract” option.

2. Choose Urban/Rural and hit on submit.

3. Choose the Village, Taluk, and the preferred “View Patta Chitta FMB Map” option.

4. Fill in other information to check the Patta Chitta Map. You can download the map if required.



I hope you know the FMB meaning now.

Read more:

How to apply FMB sketch online in Tamilnadu? How to find FMB of land survey?

Hi, Thank you for explaining the elements of the FMB sketch, Harsh. It will definitely help me in the FMB Sketch measurements calculation. FMB (Field Measurement Book) sketch is a collection of maps that are collected in volumes by the govt. at the respective Revenue Department or Village Administrative Office (VAO). An FMB sketch shows the precise dimensions of the land. Hence, it is used to verify the land measurements and boundaries of the property during a property purchase transaction. Now you know what is FMB in land records. Benefits of Having an FMB Sketch FMB sketch is an essential document required to get:

• Water connection for the building.
• Building plan approval.
• Electricity connection for the building.

Consult NoBroker’s Legal Experts if you need help in sale deed/agreement drafting, property title check, and more! How to Obtain FMB Sketch

• You are required to approach the concerned Tahsildar office to obtain an FMB sketch for a property. Let me tell you how you can obtain the FMB sketch in Delhi.
• First, you will have to go to the Taluk Office of your respective area and fill out the request form to get the FMB sketch copy of your land. You will also have to provide the ownership right and survey number to the relevant department.
• Submit the form as well as the required documents to the relevant authority. You will also have to pay the required fees as directed by the officials.
• After the verification, you’ll the FMB sketch copy of your land with a unique reference number.

Required Documents

• Request form
• Sub-division number and survey number
• Copies of documents displaying ownership right
• Aadhaar card

Eligibility

• You should be an Indian citizen.
• People who are 18 years and above are eligible to apply.
• You should possess a valid survey number for the concerned land
• The land should fall under a legally approved area.

I will also share a sample of an FMB sketch for your reference. I hope now you will be able to do the FMB sketch measurements calculation. Post a Free Property Advertisement on NoBroker to Sell/Rent Your Property Hassle-free

The land records of various states are maintained in the Thasildar’s office. These records are kept in volumes about every village in a compilation of a register or a book referred to as the FMB. The FMB full form is Field Measurement Book. In this answer, I will tell you what an FMB sketch is in detail and how to obtain FMB online.

FMB Sketch

It refers to an accumulation of map information kept in volumes by the state Government at the Thasildar’s office.

The individual survey number sketch is recorded at a scale of 1:2000 or 1:1000. These numbers are further divided into several sub-divisions. Every landowner is assigned one sub-division of this kind.

Field Measurement Book mentions the exact land dimensions and this is why these FMB sketches play an important role in property transactions as they can be used to verify the land dimensions as well as borders of a property.

As Harsh mentioned, the components of FMB include:

• F-line

• G-line

• Extension lines

• Ladder

• Subdivision lines

• Neighbouring field survey numbers

Getting FMB Sketch

As specified earlier, the FMB sketch is recorded and maintained at the office of the Thasildar. Therefore, to obtain an FMB sketch, you are required to submit a request in writing to the concerned office of the Thasildar under whose jurisdiction the land falls. I want to tell you that there are some states that allow you to obtain the FMB sketch online through their official website. For instance, in Kerala, you can get the FMB sketch through the e-Rekha website. Here’s the process for the same:

Visit the official e-Rekha portal.

• Enter all the relevant details and tap on “submit”.

• On the next page, you will view the online block-level list of FMB data with Districts.

• Tap on “Print” to obtain an FMB sketch copy

• After that, you will be redirected to the payment page.

• Here you will have to pay the required fee using your preferred payment method

• After making the required payment, just take a print of the Field Measurement Book Sketch copy of your land with unique reference no.

Read more:

How to view and download FMB sketch online?

How to apply FMB sketch online in Tamil Nadu?

I hope you like my answer on what is the full form of an FMB sketch and how to obtain FMB online.
